HB-60ML Mobile Concrete Batching Plant

  1. Home Page
  2. Products
  3. HB-60ML Mobile Concrete Batching Plant
HB-60ML Mobil Beton Santrali

HB-60ML Mobile Concrete Batching Plant

Why HB-60ML Mobile Concrete Batching Plant?

  • Easy Transportation and Fast Installation
  • One Double Axle Trailer Needed For Transportation
  • Fast Site Erection and Setup
  • No or minumum concrete foundation required
  • Designed in conjunction with international transport standards
  • Reduced Power Consumption On Account Of Short

Specification Value Unit
Compacted Concrete Output 60 m3/hr
Batch Count 60 cycle/hr
Mixer Capacity (compacted) 1 m3
Mixer Capacity 1,5 m3
Mixer Motor Power 37 kW
Aggregate Compartments Qty. 4 Quantity
Aggregate Compartment Capacity 12 m3
Aggregate Weighing Conveyor 650x13.710 mm
Mixer Feeding Conveyor 650x13.710 mm
Aggregate Weighing 2.200 kg
Cement Weighing 500 kg
Water Weighing 250 lt
Additives Weighing 20 kg



  • HB-60ML Mobil Beton Santrali
  • HB-60ML Mobil Beton Santrali
  • HB-60ML Mobil Beton Santrali
Video will be added.
