HB-30WS Stationary Concrete Batching Plant with Skip Hoist

  1. Home Page
  2. Products
  3. HB-30WS Stationary Concrete Batching Plant with Skip Hoist
HB-30WS Kovalı Sabit Beton Santrali

HB-30WS Stationary Concrete Batching Plant with Skip Hoist

Why HB-30WS Stationary Concrete Batching Plant?

  • Compact Design ,Low Maintenance and Cost Efficient
  • Easy Transportation and Fast Installation
  • One Truck Or One 40' O/T Container Needed For Transportation
  • Prompt Reply For Service And Spare Parts
  • Hardwearing Mixer Linings
  • Manufactured For Heavy Duty Operations
  • Optional Cladding Available
  • Reduced Power Consumption On Account Of Short

Specification Value Unit
Compacted Concrete Output 30 m3/hr
Batch Count 60 cycle/hr
Mixer Capacity (compacted) 0,5 m3
Mixer Capacity 0,75 m3
Mixer Motor Power 18,5 kW
Aggregate Compartments Qty. 3-4 Quantity
Aggregate Compartment Capacity 15-20 m3
Aggregate Weighing Conveyor 800x9.850 mm
Mixer Feeding Conveyor Skip Hoist -
Aggregate Weighing 1.100 kg
Cement Weighing 300 kg
Water Weighing 160 lt
Additives Weighing 20 kg
Cement Screw Conveyor 193x11.500 mm
Cement Silo 1 Quantity
Cement Silo Capacity 50 ton
